Blaze Square Micro Fire Rated Fixed LED Downlight Warm White (2700K) 5W (=50W) White

Description

The Blaze Square Micro LED Downlight is an IP64 fire rated downlight. Suitable for both domestic and commercial applications including bathroom usage, the Blaze Square Micro LED downlight comes in a white aluminium finish, and includes integrated 5W dimmable CREE LED.

Key Features

Complies with October 2010 Part L regulations
Waterproof, double insulated, IP64 - Part P
Soundproof - Part E
Fully dimmable with most triac dimmers
Equivalent to 50W halogen
Small and compact
CREE LED
Built-in driver

Specification

General
Colour	White
Construction	Die-Cast Aluminium
Dimmable	Yes
IP Rating	IP64


Dimmable	Yes

Dimensions
Cut Out	39mm (Diameter)
Length	50mm
Minimum Ceiling Depth	85mm
Width	50mm

Electrical
Energy Efficiency Rating	A
Maximum Wattage	5W
Power Factor	0.90
Voltage	240V

Light Characteristics
Beam Angle	35°
Colour Rendering Index	80
Colour Temperature	2700K Warm White
Halogen Equivalent Wattage	50W
Lumens	420 lm
Lumens Per Watt	84 lm/W

Technical Drawings

Downloads

Catalogues

LED Blaze Downlight Brochure

Technical

Blaze Fire Downlight Test Report

Blaze Micro Instructions

Fire Rated Certificate - Blaze Adjustable, Elegant. Rock n Roll, Invisible

Fire Rated Certificate - Trimless, Blaze Fixed

Specification Sheet

Blaze Square Micro Fire Rated Fixed LED Downlight Warm White (2700K) 5W (=50W) White

Blaze Square Micro Fire Rated Fixed LED Downlight Warm White (2700K) 5W (=50W) White (Unbranded)

Compare with similar products

	This item 20% Off Blaze Square Micro Fire Rated Fixed LED Downlight Warm White (2700K) 5W (=50W) White Q3DF1 FIRE BLAZSQ501WH ~~£34.15~~ ~~£40.98~~ £27.32 excl. VAT £32.78 incl. VAT 159 in Stock 20% Off Add	20% Off Blaze Square Fire Rated Fixed LED Downlight Warm White (2700K) 7W (=75W) Nickel Q3DEF FIRE BLAZSQ805NK ~~£38.10~~ ~~£45.72~~ £30.48 excl. VAT £36.58 incl. VAT 98 in Stock 20% Off Add	20% Off Blaze Square Micro Fire Rated Fixed LED Downlight Cool White (4000K) 5W (=50W) White Q4A1F FIRE BLAZSQ501CW ~~£34.15~~ ~~£40.98~~ £27.32 excl. VAT £32.78 incl. VAT 17 in Stock 20% Off Add	20% Off Blaze Square Fire Rated Adjustable LED Downlight Warm White (3000K) 7W (=75W) Chrome Q43BE FIRE BLAZAS802WW ~~£42.18~~ ~~£50.62~~ £33.74 excl. VAT £40.49 incl. VAT available to order 20% Off Add	20% Off Blaze Square Fire Rated Adjustable LED Downlight Warm White (3000K) 7W (=75W) Nickel Q43BF FIRE BLAZAS805WW ~~£42.18~~ ~~£50.62~~ £33.74 excl. VAT £40.49 incl. VAT available to order 20% Off Add	20% Off Blaze Square Micro Fire Rated Fixed LED Downlight Warm White (2700K) 5W (=50W) Nickel Q3DF2 FIRE BLAZSQ505NK ~~£34.15~~ ~~£40.98~~ £27.32 excl. VAT £32.78 incl. VAT 97 in Stock 20% Off Add	20% Off Blaze Square Fire Rated Adjustable LED Downlight Warm White (3000K) 5W (=50W) Chrome Q43BC FIRE BLAZAS502WW ~~£39.02~~ ~~£46.82~~ £31.22 excl. VAT £37.46 incl. VAT 141 in Stock 20% Off Add	20% Off Blaze Square Fire Rated Adjustable LED Downlight Warm White (3000K) 5W (=50W) White Q4366 FIRE BLAZAS501WW ~~£39.02~~ ~~£46.82~~ £31.22 excl. VAT £37.46 incl. VAT available to order 20% Off Add	20% Off Blaze Square Fire Rated Fixed LED Downlight Warm White (2700K) 7W (=75W) White Q3DEC FIRE BLAZSQ801WH ~~£38.10~~ ~~£45.72~~ £30.48 excl. VAT £36.58 incl. VAT only 2 left 20% Off Add	20% Off Blaze Square Micro Fire Rated Fixed LED Downlight Warm White (2700K) 5W (=50W) Chrome Q3DF3 FIRE BLAZSQ502CH ~~£34.15~~ ~~£40.98~~ £27.32 excl. VAT £32.78 incl. VAT 130 in Stock 20% Off Add	20% Off Blaze Square Fire Rated Fixed LED Downlight Warm White (2700K) 7W (=75W) Chrome Q3DF0 FIRE BLAZSQ802CH ~~£38.10~~ ~~£45.72~~ £30.48 excl. VAT £36.58 incl. VAT 80 in Stock 20% Off Add	20% Off Blaze Square Fire Rated Adjustable LED Downlight Warm White (3000K) 5W (=50W) Nickel Q43BD FIRE BLAZAS505WW ~~£39.02~~ ~~£46.82~~ £31.22 excl. VAT £37.46 incl. VAT 153 in Stock 20% Off Add	20% Off Blaze Square Fire Rated Adjustable LED Downlight Warm White (3000K) 7W (=75W) White Q4365 FIRE BLAZAS801WW ~~£42.18~~ ~~£50.62~~ £33.74 excl. VAT £40.49 incl. VAT 66 in Stock 20% Off Add
Cut Out	39mm (Diameter)	64mm (Diameter)	39mm (Diameter)	80mm (Diameter)	80mm (Diameter)	39mm (Diameter)	62mm (Diameter)	62mm (Diameter)	64mm (Diameter)	39mm (Diameter)	64mm (Diameter)	62mm (Diameter)	80mm (Diameter)
Minimum Ceiling Depth	85mm	70mm	85mm	75mm	75mm	85mm	77mm	77mm	70mm	85mm	70mm	77mm	75mm
Width	50mm	80mm	50mm	90mm	90mm	50mm	70mm	70mm	80mm	50mm	81mm	70mm	90mm
Maximum Wattage	5W	7W	5W	7W	7W	5W	5W	5W	7W	5W	7W	5W	7W
Colour	White	Nickel	White	Chrome	Nickel	Nickel	Chrome	White	White	Chrome	Chrome	Nickel	White
Construction	Die-Cast Aluminium	Die-Cast Aluminium	Die-Cast Aluminium	Die-cast Aluminium	Die-cast Aluminium	Die-Cast Aluminium	Die-cast Aluminium	Die-cast Aluminium	Die-Cast Aluminium	Die-Cast Aluminium	Die-Cast Aluminium	Die-cast Aluminium	Die-cast Aluminium
Colour Temperature	2700K Warm White	2700K Warm White	4000K Cool White	3000K Warm White	3000K Warm White	2700K Warm White	3000K Warm White	3000K Warm White	2700K Warm White	2700K Warm White	2700K Warm White	3000K Warm White	3000K Warm White
Lumens	420 lm	630 lm	420 lm	630 lm	630 lm	420 lm	420 lm	420 lm	630 lm	420 lm	630 lm	420 lm	630 lm
Lumens Per Watt	84 lm/W	90 lm/W	84 lm/W	90 lm/W	90 lm/W	84 lm/W	84 lm/W	84 lm/W	90 lm/W	84 lm/W	90 lm/W	84 lm/W	90 lm/W
