Grid Trimless Double LED GU10 / AR70 240V

2 x 50W White

Quicklink Q4911

Product Code FRT200SGU10 WHT

Colour (White)

Lamps

£42.24EX VAT
£50.69INC VAT
£42.24EX VAT
£50.69INC VAT
77 due in

Description

The Grid Trimless Double LED GU10 / AR70 is an adjustable downlight that takes two GU10 lamps and can be angled in any direction.

This fitting uses the GU10 / AR70 LED which is a revolutionary new style of lamp combining the big reflector and brightness of an AR70 lamp with the widely used GU10 cap with no need for a transformer.

Regular GU10 lamps can still be used with this fitting.

This product comes with a 15mm metal frame that is to be used with a 12.5mm plasterboard. If you have a double plaster board or need a larger frame please purchase the 28mm frame.

This product comes with a mounting ring which is designed to be fitted into the ceiling and plastered in before the light fixture is put into place. The downlight is installed into the hole in the ceiling and will rest on top of the mounting bracket. Once the light is fitted there will be no trim unlike the similar Grid Range of products.

Specification

General
Cap	GU10 / AR70
Colour	White
Construction	Steel
Dimmable	Yes
IP Rating	IP20

Dimensions
Cut Out	220 x 112mm (Length x Width)
Depth	115mm
Horizontal Rotation	45°
Length	210mm
Vertical Rotation	45°
Width	102mm

Electrical
Maximum Wattage	100W (2 x 50W)
Voltage	240V

Technical Drawings

Downloads

Technical

Installation Instructions Grid Metal Trimless Double GU10

Specification Sheet

Grid Trimless Double LED GU10 / AR70 240V 2 x 50W White

Grid Trimless Double LED GU10 / AR70 240V 2 x 50W White (Unbranded)
